Sawmill layout inside

Discussion in 'Logging, Mining and Industrial Railroads' started by shamus, Jan 15, 2003.

  1. shamus

    shamus Registered Member

    Joined:
    Dec 17, 2000
    Messages:
    3,688
    Likes Received:
    0
    Here is a typical sawmill layout, logs are brought up from the log pond, and are transported through the mill without turning them around. In one end and out the other all cut up :D
    [​IMG]
    Shamus[​IMG]

    [​IMG]
  2. camelot

    camelot Member

    Joined:
    Jan 12, 2003
    Messages:
    188
    Likes Received:
    0
    Fantastic , always wondered how it worked.2 questions though...

    What is the purpose of the carriage , is that split log on it and how does the carriage hold the log

    and...

    whats a gangedger ?

    Cheers

    Ian:cool:
  3. shamus

    shamus Registered Member

    Joined:
    Dec 17, 2000
    Messages:
    3,688
    Likes Received:
    0
    The carriage brings logs out of the water to the table, and no it not a split log, just my drawing
    The aim of the Edger was to remove the wane from the edge of boards, and also to make them a standard width. The press rollers were almost always powered, and were mounted with rip saws.
    Shamus[​IMG]

    [​IMG]
  4. jon-monon

    jon-monon Active Member

    Joined:
    Aug 15, 2002
    Messages:
    4,764
    Likes Received:
    0
    This kind of stuff is invaluable to us wanabees. I would have had to just guess at how to set up shop. Thanks!

    Attached Files:

    • gap.gif
      File size:
      116 bytes
      Views:
      362
  5. shamus

    shamus Registered Member

    Joined:
    Dec 17, 2000
    Messages:
    3,688
    Likes Received:
    0
    More photo's on the inside of a sawmill.

    Shamus[​IMG]

    [​IMG]

    Attached Files:

  6. 60103

    60103 Pooh Bah

    Joined:
    Mar 25, 2002
    Messages:
    5,141
    Likes Received:
    0
    There was a big lumber yard on the edge of the town I grew up in. I don't think they took in raw logs, but they did a roaring trade making construction lumber. (They weren't on the river and the river wasn't usable at that point anyway.)
    What I do remember was what seemed like acres of sawdust (large woodchip sawdust) spread over fields past where they stored the finished wood.
  7. shamus

    shamus Registered Member

    Joined:
    Dec 17, 2000
    Messages:
    3,688
    Likes Received:
    0
    Hi David, sounds like a good idea to try and model that kind of lumber yard. large woodchip sawdust all over the place. Yeah sound good to me.
    Shamus[​IMG]

    [​IMG]
  8. 60103

    60103 Pooh Bah

    Joined:
    Mar 25, 2002
    Messages:
    5,141
    Likes Received:
    0
    I think the sawdust yard might just cover a 4x8 sheet of pywood, with a double row of lumber stacks along the road in.
    Oh, I just remembered they had an icehouse (or the remains of one) down at the river end. Probably what they were keeping the sawdust for. Ice was cut from the river in winter and stored for use in summer. I think they used sawdust to insulate it.
    (This was in the fifties. There was still ice delivery in town. House across the street had an ice-box, not a refrigerator. Ice cart was horse drawn. We lived in an apartment building and we had a refrigerator, hooked up to a mechanism in the basement!)
  9. shamus

    shamus Registered Member

    Joined:
    Dec 17, 2000
    Messages:
    3,688
    Likes Received:
    0
    Hi David, thats a real nice little story, we could do with a few more on this subject
    Shamus[​IMG]

    [​IMG]
  10. jon-monon

    jon-monon Active Member

    Joined:
    Aug 15, 2002
    Messages:
    4,764
    Likes Received:
    0
    I used to go to an old fashioned ice house in the Philippines whenever we were going to have a party and get ice for the beer barrel. 1/8 block was about 1 1/2 long, 8" or 10" deep and maybe 6" thick. They used rice husks to keep 'em from sticking together. Toss a couple of those in a 55 gal. drum and a few cases of beer and all the little plastic folk get wobbly!
