A modular 180 curve

Discussion in 'Modular Layout Forum' started by ulf999, Sep 26, 2007.

  1. ulf999

    ulf999 Member

    Joined:
    Aug 14, 2007
    Messages:
    85
    Likes Received:
    0
    This spring a did a series of 4 modules that for my home layout would sneak around a table, but at modular meetings could be configured as need be. The short sides all have the same 'interface' (symmetrical along the vertical centerline)

    They are all constructed basically the same way I did my first one, so it's not as detailed :oops:. Here is the thought track plan for Märklin C-track


    [​IMG]



    [​IMG]


    [​IMG]

    Tunnelportal and retaining walls from WS
    [​IMG]


    [​IMG]

    The signal is a kit from Oregon Rail
    [​IMG]
  2. ulf999

    ulf999 Member

    Joined:
    Aug 14, 2007
    Messages:
    85
    Likes Received:
    0
    A few clickable images


    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]



  3. ulf999

    ulf999 Member

    Joined:
    Aug 14, 2007
    Messages:
    85
    Likes Received:
    0
    Some growth in place and a trainset possing [​IMG]



    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]
  4. ulf999

    ulf999 Member

    Joined:
    Aug 14, 2007
    Messages:
    85
    Likes Received:
    0
    The hidden part of the tunnel are simple ones with removable tops...

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

    Possible ways to use them
    [​IMG]

    [​IMG]

    tops off
    [​IMG]

    My home configuration
    [​IMG]
  5. ulf999

    ulf999 Member

    Joined:
    Aug 14, 2007
    Messages:
    85
    Likes Received:
    0
    and better safe than sorry...

    [​IMG]

    [​IMG]
  6. Gary S.

    Gary S. Senior Member

    Joined:
    Oct 13, 2005
    Messages:
    1,691
    Likes Received:
    0
    Ulf, you do some wonderful work! Very impressive, and again, welcome to The Gauge!
  7. ulf999

    ulf999 Member

    Joined:
    Aug 14, 2007
    Messages:
    85
    Likes Received:
    0
  8. jesso

    jesso Member

    Joined:
    Jul 21, 2006
    Messages:
    725
    Likes Received:
    0
    Thanks for sharing! You have done very nice work!
  9. nkp174

    nkp174 Active Member

    Joined:
    Oct 11, 2006
    Messages:
    1,545
    Likes Received:
    0
    Yes, very nice Ulf!

    I've got another question about the Marklin system...Are the outer rails electrically isolated so that you could operate 2-rail DC trains with a different powerpack? My understanding of 2.5rail AC is that it has one polarity on the middle studs and both rails have the other polarity. My question is if you could use the marklin track with DC trains...so that if you pick up some american 2-rail DC stuff...you can run it on your excellent modules? Certainly the rolling stock would be compatible!

    Your stuff looks great! I'm a big fan of the coal mine...so if you don't have a passenger train already...I'd build that coal mine for all your hopper cars! (are those cars Marklin?)
  10. ulf999

    ulf999 Member

    Joined:
    Aug 14, 2007
    Messages:
    85
    Likes Received:
    0
    Out of the box, the Märklin C-track does not have isolated rails, but it is easy to do:
    One just cuts/removes some 'spades':
    [​IMG]

    On my modules I have separated the rails so that I switch between DC and AC operation.
    When I run in AC mode, the center studs is '+' and the rails are '0'
    in DC mode the back rail (powered with the black wire) is '0' and
    the front rail (red wire) is '+'
    (here the center studs are non-powered)

    Yes, the cars are Marklin. They offer the same cars, with RP25+Kadees, under the Trix brand!
  11. nkp174

    nkp174 Active Member

    Joined:
    Oct 11, 2006
    Messages:
    1,545
    Likes Received:
    0
    That's cool! I thought I'd mention that since Bachmann (spectrum), Athearn, etc... would offer a greater variety of equipment...and are much cheaper than Marklin, Fleischman, Brawa, etc... That being said, I know that Marklin stuff is very nice...and lasts forever.
  12. Nomad

    Nomad Active Member

    Joined:
    Sep 26, 2006
    Messages:
    1,631
    Likes Received:
    0
    Ulf ,that is really nice. Love your scenery work. What did you draw that trackplan with?

    Loren
  13. ulf999

    ulf999 Member

    Joined:
    Aug 14, 2007
    Messages:
    85
    Likes Received:
    0
    @nkp174, I know of all them nice cars :). Most DC cars can run on M-track, once one has kadees on the Marklin stuff :)

    @grewsome, I use WinTrack 7.0
