Weathered Ballast

Discussion in 'FAQs' started by Drew1125, Sep 8, 2002.

  1. Drew1125

    Drew1125 Active Member

    Joined:
    Jan 28, 2001
    Messages:
    3,154
    Likes Received:
    0
    Thought I'd share a little technique I figured out, that allows you to bond, & weather your ballast in one step...
    I bond my ballast with 50/50 white gle & water, & a wetting agent.
    I've always used gray ballast on my mainlines, because, in this part of the world, crushed limestone is thje most prevalent type of ballast on the mains.
    After a lot of observation, it seemed to me that my model ballast was a little too pristine looking...it lacked that grimier look of the prototype.
    (I hope these pictures do justice to the color differences)
    Here's the unballasted track on cork roadbed...

    Attached Files:

  2. Drew1125

    Drew1125 Active Member

    Joined:
    Jan 28, 2001
    Messages:
    3,154
    Likes Received:
    0
    Now here's the Woodland Scenics ballast spread, & ready for bonding...

    Attached Files:

  3. Drew1125

    Drew1125 Active Member

    Joined:
    Jan 28, 2001
    Messages:
    3,154
    Likes Received:
    0
    Now, instead of just using "wet water" to wet the ballast, I use rubbing alcohol, with a few drops of India Ink, to make a black wash...this not only wets the ballast, allowing the glue to flow through it, but it also darkens the ballast, & gives it that grimy look I was shooting for.

    Attached Files:

  4. Drew1125

    Drew1125 Active Member

    Joined:
    Jan 28, 2001
    Messages:
    3,154
    Likes Received:
    0
    I don't know if these pictures really show it, but by weathering your ballast, it really blends it into the surrounding scenery more realisticaly

    Attached Files:

  5. Tyson Rayles

    Tyson Rayles Active Member

    Joined:
    Sep 26, 2001
    Messages:
    4,500
    Likes Received:
    0
    Charlie I couldn't agree with you more on using the India Ink & alcohol mix to give the ballast "grit". For the Class 1 mainline trackage into Tellico Gap (owned by the Southern and used by the Southern and L&N) I use ballast only. For the Nantahala Midland (a poor shortline with deferred maintenance) I use a 50/50 mix of ballast and dirt, for the sidings and yard pure dirt. When done with the ballast on the shortline and sidings I go back and add some "weeds and grasses". When all that is done I use the India Ink mix, then go back with dirty paint thinner and drip it between the rails on the mainline for both the NM and the Southern.
  6. marty w.

    marty w. Member

    Joined:
    Jun 11, 2002
    Messages:
    562
    Likes Received:
    0
    That's a great step saving idea.
    I'll try that. I'll about ready to start soon.
    Marty
  7. Vic

    Vic Active Member

    Joined:
    Feb 1, 2002
    Messages:
    1,771
    Likes Received:
    0
    Great tip Charlie, I've use alcohol for years but it never dawned on me to tint it with india ink:eek: :) :) :)
  8. Drew1125

    Drew1125 Active Member

    Joined:
    Jan 28, 2001
    Messages:
    3,154
    Likes Received:
    0
    This is how I did the ballast (orlack there of) on my switching layout...I just scenicked right over the track with dirt, & other ground cover...Later I added some cinders to fill it in a little.
    I wanted really trashy looking track. for an industrial branchline.

    Attached Files:

  9. jmarksbery

    jmarksbery Guest

    track

    Great looking track on both parts, I dare say, darn good tips indeed.
  10. Tyson Rayles

    Tyson Rayles Active Member

    Joined:
    Sep 26, 2001
    Messages:
    4,500
    Likes Received:
    0
    Right on the money Charlie! Excellent work! :cool:
  11. Gary Pfeil

    Gary Pfeil Active Member

    Joined:
    May 8, 2001
    Messages:
    2,593
    Likes Received:
    0
    Great idea, Charlie! I too never thought of putting India ink in the alcohol. Have a small ballasting job coming up soon, will give it a try. Thanks!

    Gary
  12. sumpter250

    sumpter250 multiscale modelbuilder

    Joined:
    Jan 19, 2002
    Messages:
    3,217
    Likes Received:
    0
    Charlie,
    I've seen people spraying the new ballast with "Windex", as a wetting agent, I wonder if Windex can be tinted with India Ink, the same as alcohol. I like the industrial track, looks just right.
    Pete
  13. Gary Pfeil

    Gary Pfeil Active Member

    Joined:
    May 8, 2001
    Messages:
    2,593
    Likes Received:
    0
    Much to my surprise, when I went to the Michaels in my area they did not have india ink, nor does the hobby store I frequent. I was wondering if I could use black water based paint to color the alcohol instead. Any opinions?

    Gary
  14. billk

    billk Active Member

    Joined:
    Jun 13, 2001
    Messages:
    1,192
    Likes Received:
    0
    Gary - Michael's not having India ink surprises me, too - the one near me has it. Michael's having it and not knowing that they have it wouldn't surprise me, though. India ink is probably too "generic" for a hobby shop, you might try a WalMart-type of place, or an office supply.

    BTW, does India ink come only in black, does anybody know? A wash made of brown ink might be usefu, for example..
  15. Casey Feedwater

    Casey Feedwater Member

    Joined:
    Jun 11, 2002
    Messages:
    828
    Likes Received:
    0
    You can buy inks in a variety of colors, Bill. Higgins is one of the more prominant brands as is Winsor and Newton. It's usually available in the art supply area of Michaels. Look for it on the same aisle as pastel chalks, colored pens/pencils, and charcoal sticks.

    Inks, chalks, brushes, acrylics, plasters, molding materials, etc. can also be ordered on-line from Dick Blick at www.dickblick.com if you don't have access to anything locally.
  16. NYCentral

    NYCentral Member

    Joined:
    Aug 29, 2002
    Messages:
    270
    Likes Received:
    0
    I also use burnt Umber and a brown. My Michaels carries a number of colors and kinds.

    Nice site Mike!
  17. billk

    billk Active Member

    Joined:
    Jun 13, 2001
    Messages:
    1,192
    Likes Received:
    0
    Trivia lesson for the day - I did a little web-searching re: India ink - by definition, it is always black.

    They make inks in lots of colors, but they're not necessarily India ink, even if black. I guess what make India ink different from 'plain' black ink is that it has a very high carbon black content, so is more black or opaque or whatever.

    Of course, there's no reason we couldn't mix any ink with alcohol or water to make washes, etc.
  18. Gary Pfeil

    Gary Pfeil Active Member

    Joined:
    May 8, 2001
    Messages:
    2,593
    Likes Received:
    0
    Question: Why is ink preferred over thinned paint?
  19. billk

    billk Active Member

    Joined:
    Jun 13, 2001
    Messages:
    1,192
    Likes Received:
    0
    I dunno - maybe the particles that give it it's color are much smaller with ink, so they can accumulate in smaller cracks and crevices, or have a more transparent effect if used as a light wash?
  20. TR-Flyer

    TR-Flyer Member

    Joined:
    Nov 25, 2001
    Messages:
    554
    Likes Received:
    0
    Hi:
    Another source for good black ink is a graphics supply store, the kind architects and engineers used to go to, to buy drafting ink. Staedler Mars makes ink in a number of colors.

    Regards,
    Ted
