    Ray Keim has released the second model from his excellent Knoll story last week (http://www.the-knoll.raykeim.com/index.html). I have spent several days studying the model and what I'm going to do with it. Well, because it's me I'm building it at as near to 1:18 as I can figure. After a daunting trip to Kinkos I was quoted $270 to have them print it up at that scale. So I am printing on my God awful HP D110 and piecing the tiles together. I am cheating with foam core support. I'm also trying to figure out some special effects. Enjoy!
