Remember That 1/6th Scale German Railroad?

Discussion in 'Getting Started' started by Mountain Man, Sep 30, 2007.

  1. Mountain Man

    Mountain Man Active Member

    Joined:
    Jan 20, 2007
    Messages:
    1,705
    Likes Received:
    0
    Remember those British guys that model that German military railroad train complete withall the extras such as tanks, artillery and troops in 1/6th scale? Well, somebody just went them one better:

    Axis History Forum :: 1/6th Scale Dora Rail gun

    But it is a model; it is on a railroad, and it's still 1/6th scale...:thumb:

    Kind of makes garden scale railroading look a tad weak, if you know what I mean.
  2. hmas

    hmas Member

    Joined:
    Mar 22, 2007
    Messages:
    216
    Likes Received:
    0
    Agreed lets see "the experts":mrgreen: try to get it around a 2' radius curve. Even I would need 80' radius curves to even think about it, my 1/32 railgun needs 10' radius, will just do 8' slowly but the flanges try to climb the rails.
    Tony
  3. Mountain Man

    Mountain Man Active Member

    Joined:
    Jan 20, 2007
    Messages:
    1,705
    Likes Received:
    0
    That is something to think about, as the engineers assigned to this gun had to lay two curved parallel trackes to serve as the traverse. Be interesting to know what their standard radius was.
  4. hmas

    hmas Member

    Joined:
    Mar 22, 2007
    Messages:
    216
    Likes Received:
    0
    I will try to decypher the german text in my "eisenbahngeschutz" book, it shows a transverse track but I do not recall any radius given, nor do the plans of the Dora.
    The K5e used a curved track when available, it saved the engineers setting up the vogel turntable
    Tony
  5. Mountain Man

    Mountain Man Active Member

    Joined:
    Jan 20, 2007
    Messages:
    1,705
    Likes Received:
    0
    I have a book specifically on the Dora Gerat; it does not specify the curve - merely that one was built to enable traverse. since the gun was mnounted on dual electric locomotives built into the chassis, it must have been a very gentle curve.
  6. hmas

    hmas Member

    Joined:
    Mar 22, 2007
    Messages:
    216
    Likes Received:
    0
    from Deutsche Eisenbahn Geschutze by Taube
    Krupp designed a loco to move the Dora two small diseasals A-B units, into a firing posn.
    Steam locos were used to transport the gun to the assembly point, they even towed the diseasals*.
    But the Dora had no motive power of its own, save the loading elevating mechs etc.

    re the curves each "pad" of the Dora had 2 wagons of 5 axles able to swivel independantly of each other so in actual fact it could have been able to use a standard radius curve. re about a 6' radius gauge 1
    *Can you tell I like steam more than diesel power!
    Tony
  7. spitfire

    spitfire Active Member

    Joined:
    Jul 28, 2002
    Messages:
    3,536
    Likes Received:
    0

    That's the same group that has the original 1/6 model RR. The owner's name is Peter Shaw and Kampfgruppe von Abt is the name of the group that he belongs to in England.

    That's the most impressive model I've ever seen!!

    Val
  8. MT Hopper

    MT Hopper MT Hopper

    Joined:
    Sep 10, 2007
    Messages:
    120
    Likes Received:
    0
    hmas, Mountain Man
    Would either of you know a source from which I might buy a three view plan of a WWII Henschel 600mm gauge 0-4-0 locomotive? I "need" to build a 1:35 scale model of the aforementioned locomotive. My friends are IPMS 1:35 scale military modelling types and I "offered" to provide animation for their spring displays via the Henschel.

    Cheers from the Heart of the Continent
    Will
  9. hmas

    hmas Member

    Joined:
    Mar 22, 2007
    Messages:
    216
    Likes Received:
    0
    I'm asking around, someone will know who or where drawings reside, HO trackwork & running gear?
  10. MT Hopper

    MT Hopper MT Hopper

    Joined:
    Sep 10, 2007
    Messages:
    120
    Likes Received:
    0
    Thanks hmas. Yes HO track and gear theoretically in 1:35 scale works out to be 22.76" or near 600mm gauge.
    Cheers from the Heart of the Continent
    Will
