Creating Store Signs for the Layout

Discussion in 'Traction Thoroughfare' started by bill937ca, Feb 1, 2007.

  1. bill937ca

    bill937ca Member

    Joined:
    Jan 16, 2007
    Messages:
    203
    Likes Received:
    0
    I took a break from working on the electrical last night to create some signs for my buildings. I looked in several trolley books and especially by By The El: Third Avenue and its El at Mid-Century for examples of signs from the 40s and 50s. By The El is very good because the photos are in color and show Third Ave, the el and many of the stores along the street.

    I created the signs in Excel using different fonts and font sizes, fill colour and font colour controls. The long thin signs are intended for the signboard in the clerestory over the shop window. The smaller signs are intended for double sided signs, hanging over the sidewalk The larger square Downtown Hardware and Eastside Plumbing signs could be applied to the side of a building. There are a couple of signs intended for the windows of my Bachmann bus terminal.

    I printed the signs on Domtar 110 lb. Laser-Inkjet Cardstock 8 1/2 x 11 sheet, that I picked up at the local Staples.

    The plan from here when I get time (or the mood strikes me) is to:

    1. cut out the sign graphic
    2. cut a piece of .060 styrene to shape
    3. use double sided adhesive mounting paper (I have MBS Stick'em)
    4. apply backing paper to the sign
    5. peel backing paper from the back side of the sign
    6. drill # 80 holes in the top of the plastic for eye-bolt hangers
    7. slide a piece of mounting wire (.028 brass wire) through the eye bolts and glue it in place with CA
    8. the rod & eye bolts grimy black or dark gray

    Attached Files:

  2. bill937ca

    bill937ca Member

    Joined:
    Jan 16, 2007
    Messages:
    203
    Likes Received:
    0
    That image came up smaller than I had hoped. So I've scanned it in halves so you can have a better look at the signs.

    Attached Files:

  3. interurban

    interurban Active Member

    Joined:
    Aug 22, 2002
    Messages:
    4,480
    Likes Received:
    0
    Great stuff Bill, These will bring the buildings to the right time frame.
  4. Herc Driver

    Herc Driver Active Member

    Joined:
    Apr 19, 2005
    Messages:
    1,593
    Likes Received:
    0
    Great idea!
  5. spitfire

    spitfire Active Member

    Joined:
    Jul 28, 2002
    Messages:
    3,536
    Likes Received:
    0
    Neat Bill! I like to make my own signs too, it's another fun part of the hobby. My problem is that I have more ideas for stores than I can possibly fit on my layout - and that's with a city that occupies a 30" x 12' chunk of real estate too!

    Val
  6. coaster

    coaster Member

    Joined:
    Jan 13, 2006
    Messages:
    65
    Likes Received:
    0
    Bill --

    One quick suggestion before you get into the actual signage: Check your spelling on the "FURNITURE" sign.

    - Paul
  7. coaster

    coaster Member

    Joined:
    Jan 13, 2006
    Messages:
    65
    Likes Received:
    0
    Disregard this post. Fingers have been doing the walking . . . in their sleep, again.
  8. bill937ca

    bill937ca Member

    Joined:
    Jan 16, 2007
    Messages:
    203
    Likes Received:
    0
    Thanks Paul. I did notice....once I printed the file. It's what happens when you work late at night!
  9. coaster

    coaster Member

    Joined:
    Jan 13, 2006
    Messages:
    65
    Likes Received:
    0
    Bill,
    I know the feeling. As indicated by that post right after my initial one in this thread.

    - Paul
  10. MasonJar

    MasonJar It's not rocket surgery

    Joined:
    Oct 31, 2002
    Messages:
    5,718
    Likes Received:
    0
    Val,

    I'd love to hear some suggestions. I am currently stumped for the (very) short list of buildings in "Marlpost"... Garage/gas station, grain elevator, cattle pen (although this is "communal"), coal and fuel dealer, ice dealer.

    Thanks!

    Andrew
  11. YmeBP

    YmeBP Member

    Joined:
    Dec 4, 2006
    Messages:
    586
    Likes Received:
    0
    I can offer you space on my server for an image as big as you need it to be and offer links to it. We are just about at that stage in our layout where scenery is going in and i've been thinking about how to print out on adhesive backed paper some of the more common signs etc.
  12. bill937ca

    bill937ca Member

    Joined:
    Jan 16, 2007
    Messages:
    203
    Likes Received:
    0
    For coal and fuel dealers this will give you some ideas:

    http://www.canadianbranchline.com/retailcoal.htm

    http://www.canadianbranchline.com/twocoal.htm

    There's also a couple of signs here:

    http://www.canadianbranchline.com/ian's.htm
