    Here is an update to this project.
    I am now working on the tracks.

    Starting with the inside half of the tracks. Here are the parts that are needed (the tracks, slats and guide posts).

    These slats are attached first.
    IMAG5409.jpg IMAG5410.jpg IMAG5411.jpg

    Now for the guide posts.
    *NOTE* The guide posts are (roughly) 4 - 5 mm apart, so that the wheels will fit properly.
    IMAG5412.jpg IMAG5413.jpg

    The first half of the inner half of the track is done.
    Last edited: Mar 3, 2015
    zathros, ASC Mclaren and Revell-Fan like this.
  2. Rhaven Blaack

    Rhaven Blaack ADMINISTRATOR Administrator Moderator

    Joined:
    Jun 12, 2009
    Messages:
    7,514
    Likes Received:
    2,451
    Here are both halves of the inner half of the track.

    Both halves are connected.

    Here are the outer halves.

    Both the outer halves and inner halves are laminated together.
    *NOTE* make certain that you leave some overlap, so that they will connect properly.
    IMAG5424.jpg IMAG5425.jpg

    Please stay tuned to your local Colonial Fleet Broadcast channels for further updates as they come in.
    zathros, ASC Mclaren and Revell-Fan like this.
  3. Revell-Fan

    Revell-Fan Co-Administrator Administrator Moderator

    Joined:
    Aug 1, 2009
    Messages:
    6,046
    Likes Received:
    3,685
    Like the real thing! :)
    Rhaven Blaack likes this.
  4. Rhaven Blaack

    Rhaven Blaack ADMINISTRATOR Administrator Moderator

    Joined:
    Jun 12, 2009
    Messages:
    7,514
    Likes Received:
    2,451
    That is my goal!!!
    Revell-Fan likes this.
  5. Rhaven Blaack

    Rhaven Blaack ADMINISTRATOR Administrator Moderator

    Joined:
    Jun 12, 2009
    Messages:
    7,514
    Likes Received:
    2,451
    The proof of concept is finished.
    I had to change the drive wheel to a 12 point wheel. After that, I wrapped the track around the wheels and everything fell into place perfectly.
    Since this is a "proof of concept" build, I did not add the blades on the tracks (there are 60 blades total).
    IMAG5426.jpg IMAG5427.jpg IMAG5428.jpg IMAG5429.jpg IMAG5430.jpg
    (*NOTE* Even though the track system is made to look realistic, it is static.)

    I have sent all of the photos and new parts sheets to Revell-Fan for review and revision. Once the revision is finished, it will be added to the rest of the add-on components.

    Please stay tuned to your local Colonial Fleet Broadcast channels for further updates as they come in.
